KDC3400FA14K08P15S12 Circuit Breaker by Eaton, Cutler Hammer or Westinghouse

EATON CURRENT LIMITING CIRCUIT BREAKER 400 AMPS MAX. 3 POLES 600 VAC WITH AUXILIARY SWITCH A2X3RTK 600 VAC 6 AMPS 125-250 VDC 0.50-0.25 AMPS AND SHUNT TRIP SNT3T11K 110-240 VAC 0.09-2.3 AMPS 110-125 VDC 1.0-1.1 AMPS AND TRIP UNIT KES3250LSI 250 AMPS RMS 310 TRIP UNIT CAT# KDC3400FA14K08P15S12 STYLE# SPECIAL1660

Inventory Code: A

Make an Offer Send to a Friend

Type: KDC

Voltage: 600 V

Poles: 3

Frame Amperage: 400 A

Trip Amperage: 250 A

Mount: Bolt-in

WHSE Code: CB4A2
