EATON PHOTOVOLTAIC GRID TIED INVERTER INPUT: MAX. DC VOLTAGE 600 VDC NOMINAL OPERATING VOLTAGE 360 VDC RANGE OF OPERATING VOLTAGE 100-515 VDC MAXIMUM INPUT CURRENT 26 Adc ENCLOSURE TYPE 3R OPERATIONAL TEMP -25 DEGREES CELSIUS TO +50 DEGREES CELSIUS OUTPUT: MAXIMUM CONTINUOUS POWER 5000 W FOR 240 VAC/277 VAC 4600 W FOR 208 VAC NOMINAL OUTPUT VOLTAGE DEFAULT 240 VAC SPLIT PHASE OPTIONAL 208-240-277 VAC SINGLE PHASE REQUIRED NOMINAL OUTPUT FREQUENCY: 60 HZ MAXIMUM CONTINUOUS CURRENT 22.5 A@ 208 VAC 22.5 A @ 240 VAC 20.5 A @ 277 VAC OPERATING VOLTAGE RANGE 186-225 V @ 208 VAC 215-260 V@ 240 VAC 248-300 V @ 277 VAC OPERATING FREQUENCY RANGE: 59.31-60.49 HZ OUT POWER FACTOR 1 CAT# PV250
