EATON PHOTOVOLTIC GRID TIED INVERTER INPUT: MAX. DC VOLTAGE 600 Vdc NOMINAL OPERATING VOLTAGE 360 Vdc RANGE OF OPERATING VOLTAGE 100-515 Vdc MAX.INPUT CURRENT 19 Adc ENCLOSURE TYPE 3R OPERATIONAL TEMP RANGE -25 DEGREES CELSIUS TO +50 DEGREES CELSIUS OUTPUT: MAXIMUM CONTINUOUS POWER 4000 W AT 240 VAC /277 VAC 3800 W AT 208 VAC NOMINAL OUTPUT VOLTAGE DEFAULT: 240 VAC SPLIT PHASE OPTINAL: 208/240/277 VAC SINGLE PHASE REQUIRED NOMINAL OUTPUT FREQUENCY 60 HZ MAXIMUM CONTINUOUS CURRENT 18.5 A @ 208 VAC 18.5 A @ 240 VAC 16.4 A @ 277 VAC OPERATING VOLTAGE RANGE 186-225 V @ 208 VAC 215-260 V @ 240 VAC 248-300 V @ 277 VAC OPERATING FREQUENCY RANGE 59.31-60.49 HZ OUTPUT POWER FACTOR 1 CAT# PV240
